Room Solutions
Integrated Lighting Systems
l
1
l
crestron.com/lighting
Crestron Green Light
®
Power Pack
GLPP Wired Switches with Cresnet
®
GLPP-SWCN 1-channel
GLPP-1SW2CN 2-channel
GLPP-1SW3CN 3-channel
GLPP Wired 0-10V Dimmers with Cresnet
®
and Power Monitoring
GLPP-DIMFLVCN-PM 1-channel
GLPP-1DIMFLV2CN-PM 2-channel
GLPP-1DIMFLV3CN-PM 3-channel
GLPP Wireless Switches with infiNET EX
TM
GLPP-SWEX 1-channel
GLPP-1SW2EX 2-channel
GLPP-1SW3EX 3-channel
GLPP Wireless 0-10V Dimmers with infiNET EX
TM
and Power Monitoring
GLPP-DIMFLVEX-PM 1-channel
GLPP-1DIMFLV2EX-PM 2-channel
GLPP-1DIMFLV3EX-PM 3-channel
4 Standalone room controller
4 Works in 120-277VAC systems
4 Ideal for new construction or retrofits
4 Wired or wireless link to central
Crestron system
4 1, 2 and 3 channel models available
4 Switched and 0-10V dimming models
available
4 Integrates with occupancy sensor and
photocell
4 Optional handheld commissioning remote
4 Supports up to two remote keypads
4 Easy keypad wiring using existing
switch-loop wiring
4 Optional handheld remote for daily use
4 Real-time energy monitoring on select
models
4 Adaptive zero-cross switching for
extended life
4 Seamless integration with Crestron
AV systems
Crestron Green Light
®
Integrated
Lighting System
GLPAC-DIMFLV4 4-Channel Integrated Lighting System
GLPAC-DIMFLV4-PM 4-Channel System with Power Monitoring
GLPAC-DIMFLV8 8-Channel Integrated Lighting System
GLPAC-DIMFLV8-PM 8-Channel System with Power Monitoring
4 Control up to 4 rooms with a single GLPAC
4 Up to 8 channels of 0-10 Volt dimming
4 Supports 100 to 277 Volt applications
4 16 Amp load rating per channel
4 Built-in 2-Series Control System
with Cresnet
®
port
4 Preloaded program for quick setup
4 Optional real time power monitoring
4 Positive air gap at each output
4 Phase-independent channels
4 Local controls for setup, testing
and verification
4 Local and remote override capability
4 Non-volatile power failure memory
Integrated Lighting Control Systems
CLS-C6 iLux
®
Integrated Lighting System
CLS-C6M iLux
®
Integrated Lighting System with Motion Detector
4 Wall-mounted integrated lighting and
shade control
4 6 channels of dimming or switching
4 6 groups of shade and drape control
4 Linkable for up to 54 lighting channels
and 54 shade groups
4 Up to 16 user-settable scenes
4 7 configurable “rocker” buttons
4 Customizable label strip
4 ON and OFF buttons
4 6 bargraphs show lighting levels and
shade positions
4 Flip-up front cover reveals setup controls
4 Easy setup from front panel or
iLux Designer software
4 Multipoint control using up to 16 keypads
4 Optional IR remote
4 Master air-gap relay
4 Integrates with 2-Series control systems
via Cresnet
®
4 Available in almond, black, or white
4 Built-in motion detector (CLS-C6M only)
4 Works out of the box with Cameo
®
keypads
and select touch panels
4 Seamless integration with GLS-SIM
4 Out-of-the-box room combine mode
Crestron Green Light
®
Integrated
Switching System
GL-IPAC-SW8 8 Circuit Switching System with LCD Interface
4 8 internal circuits for switched loads
4 Expandable to control up to 64 circuits
of switched load
4 Supports 100 to 277 Volt applications
4 16 Amp load rating per channel
4 Built-in astronomical time clock
4 Positive air gap at each output
4 Phase-independent channels
4 Local controls for setup, testing,
and verification
4 Local and remote override capability
4 Non-volatile power failure memory
4 Easy access is facilitated from the
hinged front cover
GreenLight Product Overview_02_2014_R003:Layout 1 2/18/14 12:26 PM Page 3
